Proven alloy performance
ALUXX aluminum frameset is hand-built in-house by the world leader in aluminum engineering.
Balance and stability
Frame geometry is designed to optimize the balance and roll-over capabilities of 29-inch wheels or the liveliness of 27.5-inch wheels (depending on frame size).
XC control
Suspension fork offers either 80mm or 100mm of smooth travel for added XC control.
Ram
ALUXX-Grade Aluminum, disc
Framgaffel
SR Suntour XCM30, QR, steel steerer XS: 80mm travel (27.5) S: 80mm travel (27.5) / 100mm travel (29)
Bakdämpare
N/A
Styre
Giant Connect Trail, 31.8mm XS: 730mm (27.5) S: 780mm (27.5) / 780mm (29) M: 780mm (27.5) / 780mm travel (29) L: 780mm (27.5) / 780mm (29) XL: 780mm (29) XXL: 780mm (29)
Grips
Giant Sole-O
Styrstam
Giant Sport, 7-degree XS: 40mm (27.5) S: 50mm (27.5) / 50mm (29) M: 60mm (27.5) / 60mm travel (29) L: 70mm (27.5) / 70mm (29) XL: 80mm (29) XXL: 90mm (29)
Sadelstolpe
Giant Sport, 30.9 XS: 300mm (27.5) S: 300mm (27.5) / 375mm (29) M: 375mm (27.5) / 375mm travel (29) L: 375mm (27.5) / 375mm (29) XL: 375mm (29) XXL: 375mm (29)
Sadel
Giant custom
Pedaler
MTB caged
Växelreglage
Shimano Altus M2010, 2x9
Framväxel
Shimano Altus M2020
Bakväxel
Shimano Altus M2000
Bromsar
Tektro HDC M275, hydraulic, Tektro rotors [F]180mm, [R]160mm
Broms handtag
Tektro HDC M275
Kassette
Shimano Deore HG200, 11x32
Kedja
KMC X9
Vevparti
ProWheel forged, 22/36 XS: 165mm (27.5) S: 170mm (27.5) / 170mm (29) M: 170mm (27.5) / 175mm travel (29) L: 175mm (27.5) / 175mm (29) XL: 175mm (29) XXL: 175mm (29)
Vevlager
cartridge
Fälgar
Giant GX03V 29 or 27.5, alloy, double wall, 21mm inner width
Nav
alloy, sealed bearing
Ekrar
stainless, 14g
Däck
Kenda Booster 27.5 or 29x2.2", wire bead
Extra
2.4" max tire size
